CUDA 向量化内存访问
介绍
从DRAM中读取和写入数据是CUDA编程中的基本操作之一。CUDA设备的有效内存带宽是影响CUDA函数性能最关键的因素之一，特别是当CUDA函数受内存限制时。
在这篇博客文章中，我们将展示如何通过使用向量化内存访问来提高CUDA函数的有效内存带宽。
CUDA 向量化内存访问
在下面的示例中，我们将实现一个朴素的自定义设备内存拷贝函数，并展示如何通过对不同数据类型的连续数据使用每线程8字节或16字节的向量化内存事务来提高其有效内存带宽。使用每线程8字节或16字节向量化内存事务的结果是减少了数据拷贝所需的内存事务数量，这在几乎所有用例中都能提高有效内存带宽。
#include <chrono>
#include <functional>
#include <iomanip>
#include <iostream>
#include <tuple>
#include <type_traits>
#include <vector>
#include <cuda_runtime.h>
// CUDA错误检查宏，用于检查CUDA API调用的返回值
#define CHECK_CUDA_ERROR(val) check((val), #val, __FILE__, __LINE__)
void check(cudaError_t err, const char* const func, const char* const file,
const int line)
{
if (err != cudaSuccess)
{
std::cerr << "CUDA Runtime Error at: " << file << ":" << line
<< std::endl;
std::cerr << cudaGetErrorString(err) << " " << func << std::endl;
std::exit(EXIT_FAILURE);
}
}
// 检查最后一个CUDA错误的宏
#define CHECK_LAST_CUDA_ERROR() check_last(__FILE__, __LINE__)
void check_last(const char* const file, const int line)
{
cudaError_t const err{cudaGetLastError()};
if (err != cudaSuccess)
{
std::cerr << "CUDA Runtime Error at: " << file << ":" << line
<< std::endl;
std::cerr << cudaGetErrorString(err) << std::endl;
std::exit(EXIT_FAILURE);
}
}
// 字符串居中对齐函数，用于格式化输出
std::string std_string_centered(std::string const& s, size_t width,
char pad = ' ')
{
size_tconst l{s.length()};
// 如果宽度太小则抛出异常
if (width < l)
{
throwstd::runtime_error("Width is too small.");
}
size_tconst left_pad{(width - l) / 2};
size_tconst right_pad{width - l - left_pad};
std::stringconst s_centered{std::string(left_pad, pad) + s +
std::string(right_pad, pad)};
return s_centered;
}
// 性能测量函数模板，用于测量CUDA函数的执行时间
template <class T>
float measure_performance(std::function<T(cudaStream_t)> const& bound_function,
cudaStream_t stream, unsignedint num_repeats = 100,
unsignedint num_warmups = 100)
{
cudaEvent_t start, stop;
float time;
// 创建CUDA事件用于计时
CHECK_CUDA_ERROR(cudaEventCreate(&start));
CHECK_CUDA_ERROR(cudaEventCreate(&stop));
// 预热运行，避免首次运行的开销影响测量结果
for (unsignedint i{0U}; i < num_warmups; ++i)
{
bound_function(stream);
}
CHECK_CUDA_ERROR(cudaStreamSynchronize(stream));
// 开始计时并执行多次重复测量
CHECK_CUDA_ERROR(cudaEventRecord(start, stream));
for (unsignedint i{0U}; i < num_repeats; ++i)
{
bound_function(stream);
}
CHECK_CUDA_ERROR(cudaEventRecord(stop, stream));
CHECK_CUDA_ERROR(cudaEventSynchronize(stop));
CHECK_LAST_CUDA_ERROR();
CHECK_CUDA_ERROR(cudaEventElapsedTime(&time, start, stop));
CHECK_CUDA_ERROR(cudaEventDestroy(start));
CHECK_CUDA_ERROR(cudaEventDestroy(stop));
// 计算平均延迟
floatconst latency{time / num_repeats};
return latency;
}
// 基础的自定义设备内存拷贝核函数
// 每个线程处理一个数据元素
template <typename T>
__global__ void custom_device_memcpy(T* __restrict__ output,
T const* __restrict__ input, size_t n)
{
// 计算当前线程的全局索引
size_tconst idx{blockDim.x * blockIdx.x + threadIdx.x};
// 计算网格步长，用于处理大于线程总数的数据
size_tconst stride{blockDim.x * gridDim.x};
for (size_t i{idx}; i < n; i += stride)
{
output[i] = input[i];
}
}
// 启动基础自定义设备内存拷贝的包装函数
template <typename T>
void launch_custom_device_memcpy(T* output, T const* input, size_t n,
cudaStream_t stream)
{
dim3 const threads_per_block{1024};
// 计算所需的块数，确保不超过无符号整数的最大值
dim3 const blocks_per_grid{static_cast<unsignedint>(std::min(
(n + threads_per_block.x - 1U) / threads_per_block.x,
static_cast<size_t>(std::numeric_limits<unsignedint>::max())))};
custom_device_memcpy<<<blocks_per_grid, threads_per_block, 0, stream>>>(
output, input, n);
CHECK_LAST_CUDA_ERROR();
}
// 使用共享内存作为中间缓冲区的自定义设备内存拷贝核函数
template <typename T, unsignedint BLOCK_DIM_X>
__global__ void custom_device_memcpy_shared_memory(T* __restrict__ output,
T const* __restrict__ input,
size_t n)
{
// 使用共享内存作为中间缓冲区
__shared__ T shared_memory[BLOCK_DIM_X];
size_tconst idx{blockDim.x * blockIdx.x + threadIdx.x};
size_tconst stride{blockDim.x * gridDim.x};
for (size_t i{idx}; i < n; i += stride)
{
// 先将数据从全局内存读取到共享内存
shared_memory[threadIdx.x] = input[i];
// 在这种情况下不需要同步，因为每个线程只访问自己的共享内存位置
// __syncthreads();
// 再从共享内存写入到输出的全局内存
output[i] = shared_memory[threadIdx.x];
}
}
// 启动使用共享内存的自定义设备内存拷贝的包装函数
template <typename T>
void launch_custom_device_memcpy_shared_memory(T* output, T const* input,
size_t n, cudaStream_t stream)
{
constexpr dim3 threads_per_block{1024};
dim3 const blocks_per_grid{static_cast<unsignedint>(std::min(
(n + threads_per_block.x - 1U) / threads_per_block.x,
static_cast<size_t>(std::numeric_limits<unsignedint>::max())))};
custom_device_memcpy_shared_memory<T, threads_per_block.x>
<<<blocks_per_grid, threads_per_block, 0, stream>>>(output, input, n);
CHECK_LAST_CUDA_ERROR();
}
// 优化的自定义设备内存拷贝核函数，使用向量化内存访问
// 一个线程拷贝sizeof(R)字节的数据
// 一个warp通过少数几个内存事务拷贝32 x sizeof(R)字节的数据
template <typename T, typename R = uint64_t>
__global__ void custom_device_memcpy_optimized(T* __restrict__ output,
T const* __restrict__ input,
size_t n)
{
size_tconst idx{blockDim.x * blockIdx.x + threadIdx.x};
size_tconst stride{blockDim.x * gridDim.x};
// 按照R类型的大小进行向量化访问
for (size_t i{idx}; i * sizeof(R) / sizeof(T) < n; i += stride)
{
// 检查是否可以完整地拷贝一个R大小的数据块
if ((i + 1U) * sizeof(R) / sizeof(T) < n)
{
// 使用向量化内存访问，一次拷贝sizeof(R)字节
reinterpret_cast<R*>(output)[i] =
reinterpret_cast<R const*>(input)[i];
}
else
{
// 处理剩余的不足一个R大小的数据
size_tconst start_index{i * sizeof(R) / sizeof(T)};
size_tconst remaining_units_to_copy{(n - start_index)};
for (size_t j{0}; j < remaining_units_to_copy; ++j)
{
output[start_index + j] = input[start_index + j];
}
}
}
}
// 启动优化的自定义设备内存拷贝的包装函数
template <typename T, typename R = uint64_t>
void launch_custom_device_memcpy_optimized(T* output, T const* input, size_t n,
cudaStream_t stream)
{
dim3 const threads_per_block{1024};
// 计算需要拷贝的R类型单元数量（向上取整）
size_tconst num_units_to_copy_round_up{(n * sizeof(T) + sizeof(R) - 1U) /
sizeof(R)};
dim3 const blocks_per_grid{static_cast<unsignedint>(std::min(
(num_units_to_copy_round_up + threads_per_block.x - 1U) /
threads_per_block.x,
static_cast<size_t>(std::numeric_limits<unsignedint>::max())))};
custom_device_memcpy_optimized<<<blocks_per_grid, threads_per_block, 0,
stream>>>(output, input, n);
CHECK_LAST_CUDA_ERROR();
}
// 使用CUDA官方内存拷贝函数的包装函数
template <typename T>
void launch_official_device_memcpy(T* output, T const* input, size_t n,
cudaStream_t stream)
{
CHECK_CUDA_ERROR(cudaMemcpyAsync(output, input, n * sizeof(T),
cudaMemcpyDeviceToDevice, stream));
}
// 初始化缓冲区，使数据单元的值等于其索引
template <typename T, std::enable_if_t<std::is_integral<T>::value, bool> = true>
void initialize_buffer(T* buffer, size_t n)
{
for (size_t i{0}; i < n; ++i)
{
buffer[i] = static_cast<T>(
i % static_cast<size_t>(std::numeric_limits<T>::max()));
}
}
// 验证缓冲区数据的正确性
template <typename T, std::enable_if_t<std::is_integral<T>::value, bool> = true>
void verify_buffer(T* buffer, size_t n)
{
for (size_t i{0}; i < n; ++i)
{
if (buffer[i] != static_cast<T>(i % static_cast<size_t>(
std::numeric_limits<T>::max())))
{
std::cerr << "Verification failed at index: " << i << std::endl;
std::exit(EXIT_FAILURE);
}
}
}
// 测量自定义设备内存拷贝性能的函数
// 给定要拷贝的单元数量、使用的设备内存拷贝函数以及重复和预热次数
template <typename T>
float measure_custom_device_memcpy_performance(
size_t n,
std::function<void(T*, T const*, size_t, cudaStream_t)> const&
device_memcpy_function,
int num_repeats = 100, int num_warmups = 100)
{
cudaStream_t stream;
CHECK_CUDA_ERROR(cudaStreamCreateWithFlags(&stream, cudaStreamNonBlocking));
// 准备主机端的输入和输出缓冲区
std::vector<T> input(n);
std::vector<T> output(n, static_cast<T>(0));
initialize_buffer(input.data(), n);
// 分配设备端内存
T* d_input;
T* d_output;
CHECK_CUDA_ERROR(cudaMalloc(&d_input, n * sizeof(T)));
CHECK_CUDA_ERROR(cudaMalloc(&d_output, n * sizeof(T)));
// 将数据从主机拷贝到设备
CHECK_CUDA_ERROR(cudaMemcpyAsync(d_input, input.data(), n * sizeof(T),
cudaMemcpyHostToDevice, stream));
CHECK_CUDA_ERROR(cudaMemcpyAsync(d_output, output.data(), n * sizeof(T),
cudaMemcpyHostToDevice, stream));
// 运行一次设备内存拷贝以检查正确性
device_memcpy_function(d_output, d_input, n, stream);
CHECK_CUDA_ERROR(cudaMemcpyAsync(output.data(), d_output, n * sizeof(T),
cudaMemcpyDeviceToHost, stream));
CHECK_CUDA_ERROR(cudaStreamSynchronize(stream));
// 验证设备内存拷贝的正确性
verify_buffer(output.data(), n);
// 计算数据大小和性能指标
size_tconst num_bytes{n * sizeof(T)};
floatconst num_giga_bytes{static_cast<float>(num_bytes) / (1 << 30)};
// 创建绑定函数用于性能测量
std::function<void(cudaStream_t)> function{std::bind(
device_memcpy_function, d_output, d_input, n, std::placeholders::_1)};
// 测量延迟并计算带宽
floatconst latency{
measure_performance(function, stream, num_repeats, num_warmups)};
std::cout << std::fixed << std::setprecision(3) << "Latency: " << latency
<< " ms" << std::endl;
std::cout << "Effective Bandwitdh: "
<< 2.f * num_giga_bytes / (latency / 1000) << " GB/s"
<< std::endl;
// 清理设备内存
CHECK_CUDA_ERROR(cudaFree(d_input));
CHECK_CUDA_ERROR(cudaFree(d_output));
CHECK_CUDA_ERROR(cudaStreamDestroy(stream));
// 查询设备名称和峰值内存带宽
int device_id{0};
cudaGetDevice(&device_id);
cudaDeviceProp device_prop;
cudaGetDeviceProperties(&device_prop, device_id);
floatconst peak_bandwidth{
static_cast<float>(2.0 * device_prop.memoryClockRate *
(device_prop.memoryBusWidth / 8) / 1.0e6)};
std::cout << "Percentage of Peak Bandwitdh: "
<< 2.f * num_giga_bytes / (latency / 1000) / peak_bandwidth * 100
<< "%" << std::endl;
return latency;
}
int main()
{
constexprunsignedint num_repeats{10U};
constexprunsignedint num_warmups{10U};
constexprsize_t tensor_size_small{1U * 64U * 64U * 64U};
constexprsize_t tensor_size_medium{1U * 128U * 128U * 128U};
constexprsize_t tensor_size_large{1U * 512U * 512U * 512U};
constexprsize_t string_width{50U};
std::cout << std_string_centered("", string_width, '~') << std::endl;
std::cout << std_string_centered("NVIDIA GPU Device Info", string_width,
' ')
<< std::endl;
std::cout << std_string_centered("", string_width, '~') << std::endl;
// Query deive name and peak memory bandwidth.
int device_id{0};
cudaGetDevice(&device_id);
cudaDeviceProp device_prop;
cudaGetDeviceProperties(&device_prop, device_id);
std::cout << "Device Name: " << device_prop.name << std::endl;
floatconst memory_size{static_cast<float>(device_prop.totalGlobalMem) /
(1 << 30)};
std::cout << "Memory Size: " << memory_size << " GB" << std::endl;
floatconst peak_bandwidth{
static_cast<float>(2.0f * device_prop.memoryClockRate *
(device_prop.memoryBusWidth / 8) / 1.0e6)};
std::cout << "Peak Bandwitdh: " << peak_bandwidth << " GB/s" << std::endl;
std::cout << std::endl;
// Measure CUDA official memcpy performance for different tensor sizes.
std::cout << std_string_centered("", string_width, '*') << std::endl;
std::cout << std_string_centered("CUDA Official Memcpy", string_width, ' ')
<< std::endl;
std::cout << std_string_centered("", string_width, '*') << std::endl;
for (size_t tensor_size :
{tensor_size_small, tensor_size_medium, tensor_size_large})
{
std::stringconst tensor_size_string{std::string("Tensor Size: ") +
std::to_string(tensor_size) +
std::string(" Units")};
std::cout << std_string_centered("", string_width, '=') << std::endl;
std::cout << std_string_centered(tensor_size_string, string_width, ' ')
<< std::endl;
std::cout << std_string_centered("", string_width, '=') << std::endl;
std::cout << std_string_centered("", string_width, '-') << std::endl;
std::cout << std_string_centered("Unit Size: 1 Byte", string_width, ' ')
<< std::endl;
std::cout << std_string_centered("", string_width, '-') << std::endl;
measure_custom_device_memcpy_performance<int8_t>(
tensor_size, launch_official_device_memcpy<int8_t>, num_repeats,
num_warmups);
std::cout << std_string_centered("", string_width, '-') << std::endl;
std::cout << std_string_centered("Unit Size: 2 Byte", string_width, ' ')
<< std::endl;
std::cout << std_string_centered("", string_width, '-') << std::endl;
measure_custom_device_memcpy_performance<int16_t>(
tensor_size, launch_official_device_memcpy<int16_t>, num_repeats,
num_warmups);
std::cout << std_string_centered("", string_width, '-') << std::endl;
std::cout << std_string_centered("Unit Size: 4 Byte", string_width, ' ')
<< std::endl;
std::cout << std_string_centered("", string_width, '-') << std::endl;
measure_custom_device_memcpy_performance<int32_t>(
tensor_size, launch_official_device_memcpy<int32_t>, num_repeats,
num_warmups);
std::cout << std_string_centered("", string_width, '-') << std::endl;
std::cout << std_string_centered("Unit Size: 8 Byte", string_width, ' ')
<< std::endl;
std::cout << std_string_centered("", string_width, '-') << std::endl;
measure_custom_device_memcpy_performance<int64_t>(
tensor_size, launch_official_device_memcpy<int64_t>, num_repeats,
num_warmups);
}
std::cout << std::endl;
// Measure the latency and bandwidth of custom device memcpy for different
// tensor sizes.
std::cout << std_string_centered("", string_width, '*') << std::endl;
std::cout << std_string_centered("Custom Device Memcpy", string_width, ' ')
<< std::endl;
std::cout << std_string_centered("", string_width, '*') << std::endl;
for (size_t tensor_size :
{tensor_size_small, tensor_size_medium, tensor_size_large})
{
std::stringconst tensor_size_string{std::string("Tensor Size: ") +
std::to_string(tensor_size) +
std::string(" Units")};
std::cout << std_string_centered("", string_width, '=') << std::endl;
std::cout << std_string_centered(tensor_size_string, string_width, ' ')
<< std::endl;
std::cout << std_string_centered("", string_width, '=') << std::endl;
std::cout << std_string_centered("", string_width, '-') << std::endl;
std::cout << std_string_centered("Unit Size: 1 Byte", string_width, ' ')
<< std::endl;
std::cout << std_string_centered("", string_width, '-') << std::endl;
measure_custom_device_memcpy_performance<int8_t>(
tensor_size, launch_custom_device_memcpy<int8_t>, num_repeats,
num_warmups);
std::cout << std_string_centered("", string_width, '-') << std::endl;
std::cout << std_string_centered("Unit Size: 2 Byte", string_width, ' ')
<< std::endl;
std::cout << std_string_centered("", string_width, '-') << std::endl;
measure_custom_device_memcpy_performance<int16_t>(
tensor_size, launch_custom_device_memcpy<int16_t>, num_repeats,
num_warmups);
std::cout << std_string_centered("", string_width, '-') << std::endl;
std::cout << std_string_centered("Unit Size: 4 Byte", string_width, ' ')
<< std::endl;
std::cout << std_string_centered("", string_width, '-') << std::endl;
measure_custom_device_memcpy_performance<int32_t>(
tensor_size, launch_custom_device_memcpy<int32_t>, num_repeats,
num_warmups);
std::cout << std_string_centered("", string_width, '-') << std::endl;
std::cout << std_string_centered("Unit Size: 8 Byte", string_width, ' ')
<< std::endl;
std::cout << std_string_centered("", string_width, '-') << std::endl;
measure_custom_device_memcpy_performance<int64_t>(
tensor_size, launch_custom_device_memcpy<int64_t>, num_repeats,
num_warmups);
}
std::cout << std::endl;
// Conclusions:
// 1. The more units of data we copy, the higher the bandwidth.
// 2. The larger the unit of the data, the higher the bandwidth.
// Check if shared memory can improve the latency of custom device memcpy.
std::cout << std_string_centered("", string_width, '*') << std::endl;
std::cout << std_string_centered("Custom Device Memcpy with Shared Memory",
string_width, ' ')
<< std::endl;
std::cout << std_string_centered("", string_width, '*') << std::endl;
for (size_t tensor_size :
{tensor_size_small, tensor_size_medium, tensor_size_large})
{
std::stringconst tensor_size_string{std::string("Tensor Size: ") +
std::to_string(tensor_size) +
std::string(" Units")};
std::cout << std_string_centered("", string_width, '=') << std::endl;
std::cout << std_string_centered(tensor_size_string, string_width, ' ')
<< std::endl;
std::cout << std_string_centered("", string_width, '=') << std::endl;
std::cout << std_string_centered("", string_width, '-') << std::endl;
std::cout << std_string_centered("Unit Size: 1 Byte", string_width, ' ')
<< std::endl;
std::cout << std_string_centered("", string_width, '-') << std::endl;
measure_custom_device_memcpy_performance<int8_t>(
tensor_size, launch_custom_device_memcpy_shared_memory<int8_t>,
num_repeats, num_warmups);
std::cout << std_string_centered("", string_width, '-') << std::endl;
std::cout << std_string_centered("Unit Size: 2 Byte", string_width, ' ')
<< std::endl;
std::cout << std_string_centered("", string_width, '-') << std::endl;
measure_custom_device_memcpy_performance<int16_t>(
tensor_size, launch_custom_device_memcpy_shared_memory<int16_t>,
num_repeats, num_warmups);
std::cout << std_string_centered("", string_width, '-') << std::endl;
std::cout << std_string_centered("Unit Size: 4 Byte", string_width, ' ')
<< std::endl;
std::cout << std_string_centered("", string_width, '-') << std::endl;
measure_custom_device_memcpy_performance<int32_t>(
tensor_size, launch_custom_device_memcpy_shared_memory<int32_t>,
num_repeats, num_warmups);
std::cout << std_string_centered("", string_width, '-') << std::endl;
std::cout << std_string_centered("Unit Size: 8 Byte", string_width, ' ')
<< std::endl;
std::cout << std_string_centered("", string_width, '-') << std::endl;
measure_custom_device_memcpy_performance<int64_t>(
tensor_size, launch_custom_device_memcpy_shared_memory<int64_t>,
num_repeats, num_warmups);
}
std::cout << std::endl;
// Conclusions:
// 1. The effect of using shared memory for improving the latency of custom
// device memcpy is not obvious.
// Improve the latency of custom device memcpy when the unit of the data is
// small.
std::cout << std_string_centered("", string_width, '*') << std::endl;
std::cout << std_string_centered(
"Custom Device Memcpy 4-Byte Copy Per Thread",
string_width, ' ')
<< std::endl;
std::cout << std_string_centered("", string_width, '*') << std::endl;
for (size_t tensor_size :
{tensor_size_small, tensor_size_medium, tensor_size_large})
{
std::stringconst tensor_size_string{std::string("Tensor Size: ") +
std::to_string(tensor_size) +
std::string(" Units")};
std::cout << std_string_centered("", string_width, '=') << std::endl;
std::cout << std_string_centered(tensor_size_string, string_width, ' ')
<< std::endl;
std::cout << std_string_centered("", string_width, '=') << std::endl;
std::cout << std_string_centered("", string_width, '-') << std::endl;
std::cout << std_string_centered("Unit Size: 1 Byte", string_width, ' ')
<< std::endl;
std::cout << std_string_centered("", string_width, '-') << std::endl;
measure_custom_device_memcpy_performance<int8_t>(
tensor_size,
launch_custom_device_memcpy_optimized<int8_t, uint32_t>,
num_repeats, num_warmups);
std::cout << std_string_centered("", string_width, '-') << std::endl;
std::cout << std_string_centered("Unit Size: 2 Byte", string_width, ' ')
<< std::endl;
std::cout << std_string_centered("", string_width, '-') << std::endl;
measure_custom_device_memcpy_performance<int16_t>(
tensor_size,
launch_custom_device_memcpy_optimized<int16_t, uint32_t>,
num_repeats, num_warmups);
std::cout << std_string_centered("", string_width, '-') << std::endl;
std::cout << std_string_centered("Unit Size: 4 Byte", string_width, ' ')
<< std::endl;
std::cout << std_string_centered("", string_width, '-') << std::endl;
measure_custom_device_memcpy_performance<int32_t>(
tensor_size,
launch_custom_device_memcpy_optimized<int32_t, uint32_t>,
num_repeats, num_warmups);
std::cout << std_string_centered("", string_width, '-') << std::endl;
std::cout << std_string_centered("Unit Size: 8 Byte", string_width, ' ')
<< std::endl;
std::cout << std_string_centered("", string_width, '-') << std::endl;
measure_custom_device_memcpy_performance<int64_t>(
tensor_size,
launch_custom_device_memcpy_optimized<int64_t, uint32_t>,
num_repeats, num_warmups);
}
std::cout << std::endl;
std::cout << std_string_centered("", string_width, '*') << std::endl;
std::cout << std_string_centered(
"Custom Device Memcpy 8-Byte Copy Per Thread",
string_width, ' ')
<< std::endl;
std::cout << std_string_centered("", string_width, '*') << std::endl;
for (size_t tensor_size :
{tensor_size_small, tensor_size_medium, tensor_size_large})
{
std::stringconst tensor_size_string{std::string("Tensor Size: ") +
std::to_string(tensor_size) +
std::string(" Units")};
std::cout << std_string_centered("", string_width, '=') << std::endl;
std::cout << std_string_centered(tensor_size_string, string_width, ' ')
<< std::endl;
std::cout << std_string_centered("", string_width, '=') << std::endl;
std::cout << std_string_centered("", string_width, '-') << std::endl;
std::cout << std_string_centered("Unit Size: 1 Byte", string_width, ' ')
<< std::endl;
std::cout << std_string_centered("", string_width, '-') << std::endl;
measure_custom_device_memcpy_performance<int8_t>(
tensor_size,
launch_custom_device_memcpy_optimized<int8_t, uint64_t>,
num_repeats, num_warmups);
std::cout << std_string_centered("", string_width, '-') << std::endl;
std::cout << std_string_centered("Unit Size: 2 Byte", string_width, ' ')
<< std::endl;
std::cout << std_string_centered("", string_width, '-') << std::endl;
measure_custom_device_memcpy_performance<int16_t>(
tensor_size,
launch_custom_device_memcpy_optimized<int16_t, uint64_t>,
num_repeats, num_warmups);
std::cout << std_string_centered("", string_width, '-') << std::endl;
std::cout << std_string_centered("Unit Size: 4 Byte", string_width, ' ')
<< std::endl;
std::cout << std_string_centered("", string_width, '-') << std::endl;
measure_custom_device_memcpy_performance<int32_t>(
tensor_size,
launch_custom_device_memcpy_optimized<int32_t, uint64_t>,
num_repeats, num_warmups);
std::cout << std_string_centered("", string_width, '-') << std::endl;
std::cout << std_string_centered("Unit Size: 8 Byte", string_width, ' ')
<< std::endl;
std::cout << std_string_centered("", string_width, '-') << std::endl;
measure_custom_device_memcpy_performance<int64_t>(
tensor_size,
launch_custom_device_memcpy_optimized<int64_t, uint64_t>,
num_repeats, num_warmups);
}
std::cout << std::endl;
std::cout << std_string_centered("", string_width, '*') << std::endl;
std::cout << std_string_centered(
"Custom Device Memcpy 16-Byte Copy Per Thread",
string_width, ' ')
<< std::endl;
std::cout << std_string_centered("", string_width, '*') << std::endl;
for (size_t tensor_size :
{tensor_size_small, tensor_size_medium, tensor_size_large})
{
std::stringconst tensor_size_string{std::string("Tensor Size: ") +
std::to_string(tensor_size) +
std::string(" Units")};
std::cout << std_string_centered("", string_width, '=') << std::endl;
std::cout << std_string_centered(tensor_size_string, string_width, ' ')
<< std::endl;
std::cout << std_string_centered("", string_width, '=') << std::endl;
std::cout << std_string_centered("", string_width, '-') << std::endl;
std::cout << std_string_centered("Unit Size: 1 Byte", string_width, ' ')
<< std::endl;
std::cout << std_string_centered("", string_width, '-') << std::endl;
measure_custom_device_memcpy_performance<int8_t>(
tensor_size, launch_custom_device_memcpy_optimized<int8_t, uint4>,
num_repeats, num_warmups);
std::cout << std_string_centered("", string_width, '-') << std::endl;
std::cout << std_string_centered("Unit Size: 2 Byte", string_width, ' ')
<< std::endl;
std::cout << std_string_centered("", string_width, '-') << std::endl;
measure_custom_device_memcpy_performance<int16_t>(
tensor_size, launch_custom_device_memcpy_optimized<int16_t, uint4>,
num_repeats, num_warmups);
std::cout << std_string_centered("", string_width, '-') << std::endl;
std::cout << std_string_centered("Unit Size: 4 Byte", string_width, ' ')
<< std::endl;
std::cout << std_string_centered("", string_width, '-') << std::endl;
measure_custom_device_memcpy_performance<int32_t>(
tensor_size, launch_custom_device_memcpy_optimized<int32_t, uint4>,
num_repeats, num_warmups);
std::cout << std_string_centered("", string_width, '-') << std::endl;
std::cout << std_string_centered("Unit Size: 8 Byte", string_width, ' ')
<< std::endl;
std::cout << std_string_centered("", string_width, '-') << std::endl;
measure_custom_device_memcpy_performance<int64_t>(
tensor_size, launch_custom_device_memcpy_optimized<int64_t, uint4>,
num_repeats, num_warmups);
}
std::cout << std::endl;
// Conclusions:
// 1. Copying data in units of 8 bytes or 16 bytes can improve the latency
// of custom device memcpy.
}
该CUDA程序在配有CUDA 12.0的NVIDIA RTX 3090 GPU上进行编译和性能分析。
$ nvcc memcpy.cu -o memcpy -std=c++14
$ ./memcpy
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
NVIDIA GPU Device Info
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
Device Name: NVIDIA GeForce RTX 3090
Memory Size: 23.6694 GB
Peak Bandwitdh: 936.096 GB/s
**************************************************
CUDA Official Memcpy
**************************************************
==================================================
Tensor Size: 262144 Units
==================================================
--------------------------------------------------
Unit Size: 1 Byte
--------------------------------------------------
Latency: 0.002 ms
Effective Bandwitdh: 217.362 GB/s
Percentage of Peak Bandwitdh: 23.220%
--------------------------------------------------
Unit Size: 2 Byte
--------------------------------------------------
Latency: 0.002 ms
Effective Bandwitdh: 414.641 GB/s
Percentage of Peak Bandwitdh: 44.295%
--------------------------------------------------
Unit Size: 4 Byte
--------------------------------------------------
Latency: 0.003 ms
Effective Bandwitdh: 706.425 GB/s
Percentage of Peak Bandwitdh: 75.465%
--------------------------------------------------
Unit Size: 8 Byte
--------------------------------------------------
Latency: 0.004 ms
Effective Bandwitdh: 1030.999 GB/s
Percentage of Peak Bandwitdh: 110.138%
==================================================
Tensor Size: 2097152 Units
==================================================
--------------------------------------------------
Unit Size: 1 Byte
--------------------------------------------------
Latency: 0.004 ms
Effective Bandwitdh: 1059.638 GB/s
Percentage of Peak Bandwitdh: 113.198%
--------------------------------------------------
Unit Size: 2 Byte
--------------------------------------------------
Latency: 0.011 ms
Effective Bandwitdh: 719.754 GB/s
Percentage of Peak Bandwitdh: 76.889%
--------------------------------------------------
Unit Size: 4 Byte
--------------------------------------------------
Latency: 0.023 ms
Effective Bandwitdh: 675.261 GB/s
Percentage of Peak Bandwitdh: 72.136%
--------------------------------------------------
Unit Size: 8 Byte
--------------------------------------------------
Latency: 0.043 ms
Effective Bandwitdh: 719.330 GB/s
Percentage of Peak Bandwitdh: 76.844%
==================================================
Tensor Size: 134217728 Units
==================================================
--------------------------------------------------
Unit Size: 1 Byte
--------------------------------------------------
Latency: 0.321 ms
Effective Bandwitdh: 778.091 GB/s
Percentage of Peak Bandwitdh: 83.121%
--------------------------------------------------
Unit Size: 2 Byte
--------------------------------------------------
Latency: 0.640 ms
Effective Bandwitdh: 781.539 GB/s
Percentage of Peak Bandwitdh: 83.489%
--------------------------------------------------
Unit Size: 4 Byte
--------------------------------------------------
Latency: 1.275 ms
Effective Bandwitdh: 784.214 GB/s
Percentage of Peak Bandwitdh: 83.775%
--------------------------------------------------
Unit Size: 8 Byte
--------------------------------------------------
Latency: 2.560 ms
Effective Bandwitdh: 781.282 GB/s
Percentage of Peak Bandwitdh: 83.462%
**************************************************
Custom Device Memcpy
**************************************************
==================================================
Tensor Size: 262144 Units
==================================================
--------------------------------------------------
Unit Size: 1 Byte
--------------------------------------------------
Latency: 0.003 ms
Effective Bandwitdh: 183.399 GB/s
Percentage of Peak Bandwitdh: 19.592%
--------------------------------------------------
Unit Size: 2 Byte
--------------------------------------------------
Latency: 0.003 ms
Effective Bandwitdh: 354.443 GB/s
Percentage of Peak Bandwitdh: 37.864%
--------------------------------------------------
Unit Size: 4 Byte
--------------------------------------------------
Latency: 0.003 ms
Effective Bandwitdh: 681.196 GB/s
Percentage of Peak Bandwitdh: 72.770%
--------------------------------------------------
Unit Size: 8 Byte
--------------------------------------------------
Latency: 0.003 ms
Effective Bandwitdh: 1192.093 GB/s
Percentage of Peak Bandwitdh: 127.347%
==================================================
Tensor Size: 2097152 Units
==================================================
--------------------------------------------------
Unit Size: 1 Byte
--------------------------------------------------
Latency: 0.010 ms
Effective Bandwitdh: 378.747 GB/s
Percentage of Peak Bandwitdh: 40.460%
--------------------------------------------------
Unit Size: 2 Byte
--------------------------------------------------
Latency: 0.018 ms
Effective Bandwitdh: 445.593 GB/s
Percentage of Peak Bandwitdh: 47.601%
--------------------------------------------------
Unit Size: 4 Byte
--------------------------------------------------
Latency: 0.024 ms
Effective Bandwitdh: 660.732 GB/s
Percentage of Peak Bandwitdh: 70.584%
--------------------------------------------------
Unit Size: 8 Byte
--------------------------------------------------
Latency: 0.042 ms
Effective Bandwitdh: 737.140 GB/s
Percentage of Peak Bandwitdh: 78.746%
==================================================
Tensor Size: 134217728 Units
==================================================
--------------------------------------------------
Unit Size: 1 Byte
--------------------------------------------------
Latency: 0.972 ms
Effective Bandwitdh: 257.207 GB/s
Percentage of Peak Bandwitdh: 27.477%
--------------------------------------------------
Unit Size: 2 Byte
--------------------------------------------------
Latency: 1.076 ms
Effective Bandwitdh: 464.543 GB/s
Percentage of Peak Bandwitdh: 49.626%
--------------------------------------------------
Unit Size: 4 Byte
--------------------------------------------------
Latency: 1.369 ms
Effective Bandwitdh: 730.586 GB/s
Percentage of Peak Bandwitdh: 78.046%
--------------------------------------------------
Unit Size: 8 Byte
--------------------------------------------------
Latency: 2.536 ms
Effective Bandwitdh: 788.727 GB/s
Percentage of Peak Bandwitdh: 84.257%
**************************************************
Custom Device Memcpy with Shared Memory
**************************************************
==================================================
Tensor Size: 262144 Units
==================================================
--------------------------------------------------
Unit Size: 1 Byte
--------------------------------------------------
Latency: 0.003 ms
Effective Bandwitdh: 175.995 GB/s
Percentage of Peak Bandwitdh: 18.801%
--------------------------------------------------
Unit Size: 2 Byte
--------------------------------------------------
Latency: 0.003 ms
Effective Bandwitdh: 328.853 GB/s
Percentage of Peak Bandwitdh: 35.130%
--------------------------------------------------
Unit Size: 4 Byte
--------------------------------------------------
Latency: 0.003 ms
Effective Bandwitdh: 653.481 GB/s
Percentage of Peak Bandwitdh: 69.809%
--------------------------------------------------
Unit Size: 8 Byte
--------------------------------------------------
Latency: 0.003 ms
Effective Bandwitdh: 1128.192 GB/s
Percentage of Peak Bandwitdh: 120.521%
==================================================
Tensor Size: 2097152 Units
==================================================
--------------------------------------------------
Unit Size: 1 Byte
--------------------------------------------------
Latency: 0.011 ms
Effective Bandwitdh: 353.213 GB/s
Percentage of Peak Bandwitdh: 37.733%
--------------------------------------------------
Unit Size: 2 Byte
--------------------------------------------------
Latency: 0.018 ms
Effective Bandwitdh: 433.488 GB/s
Percentage of Peak Bandwitdh: 46.308%
--------------------------------------------------
Unit Size: 4 Byte
--------------------------------------------------
Latency: 0.024 ms
Effective Bandwitdh: 650.261 GB/s
Percentage of Peak Bandwitdh: 69.465%
--------------------------------------------------
Unit Size: 8 Byte
--------------------------------------------------
Latency: 0.042 ms
Effective Bandwitdh: 737.864 GB/s
Percentage of Peak Bandwitdh: 78.824%
==================================================
Tensor Size: 134217728 Units
==================================================
--------------------------------------------------
Unit Size: 1 Byte
--------------------------------------------------
Latency: 1.011 ms
Effective Bandwitdh: 247.181 GB/s
Percentage of Peak Bandwitdh: 26.406%
--------------------------------------------------
Unit Size: 2 Byte
--------------------------------------------------
Latency: 1.113 ms
Effective Bandwitdh: 449.172 GB/s
Percentage of Peak Bandwitdh: 47.984%
--------------------------------------------------
Unit Size: 4 Byte
--------------------------------------------------
Latency: 1.391 ms
Effective Bandwitdh: 718.748 GB/s
Percentage of Peak Bandwitdh: 76.781%
--------------------------------------------------
Unit Size: 8 Byte
--------------------------------------------------
Latency: 2.546 ms
Effective Bandwitdh: 785.429 GB/s
Percentage of Peak Bandwitdh: 83.905%
**************************************************
Custom Device Memcpy 4-Byte Copy Per Thread
**************************************************
==================================================
Tensor Size: 262144 Units
==================================================
--------------------------------------------------
Unit Size: 1 Byte
--------------------------------------------------
Latency: 0.002 ms
Effective Bandwitdh: 238.419 GB/s
Percentage of Peak Bandwitdh: 25.469%
--------------------------------------------------
Unit Size: 2 Byte
--------------------------------------------------
Latency: 0.002 ms
Effective Bandwitdh: 437.842 GB/s
Percentage of Peak Bandwitdh: 46.773%
--------------------------------------------------
Unit Size: 4 Byte
--------------------------------------------------
Latency: 0.003 ms
Effective Bandwitdh: 684.251 GB/s
Percentage of Peak Bandwitdh: 73.096%
--------------------------------------------------
Unit Size: 8 Byte
--------------------------------------------------
Latency: 0.004 ms
Effective Bandwitdh: 1003.868 GB/s
Percentage of Peak Bandwitdh: 107.240%
==================================================
Tensor Size: 2097152 Units
==================================================
--------------------------------------------------
Unit Size: 1 Byte
--------------------------------------------------
Latency: 0.004 ms
Effective Bandwitdh: 968.812 GB/s
Percentage of Peak Bandwitdh: 103.495%
--------------------------------------------------
Unit Size: 2 Byte
--------------------------------------------------
Latency: 0.012 ms
Effective Bandwitdh: 675.168 GB/s
Percentage of Peak Bandwitdh: 72.126%
--------------------------------------------------
Unit Size: 4 Byte
--------------------------------------------------
Latency: 0.024 ms
Effective Bandwitdh: 660.196 GB/s
Percentage of Peak Bandwitdh: 70.527%
--------------------------------------------------
Unit Size: 8 Byte
--------------------------------------------------
Latency: 0.045 ms
Effective Bandwitdh: 690.443 GB/s
Percentage of Peak Bandwitdh: 73.758%
==================================================
Tensor Size: 134217728 Units
==================================================
--------------------------------------------------
Unit Size: 1 Byte
--------------------------------------------------
Latency: 0.366 ms
Effective Bandwitdh: 682.529 GB/s
Percentage of Peak Bandwitdh: 72.912%
--------------------------------------------------
Unit Size: 2 Byte
--------------------------------------------------
Latency: 0.722 ms
Effective Bandwitdh: 692.125 GB/s
Percentage of Peak Bandwitdh: 73.937%
--------------------------------------------------
Unit Size: 4 Byte
--------------------------------------------------
Latency: 1.422 ms
Effective Bandwitdh: 703.431 GB/s
Percentage of Peak Bandwitdh: 75.145%
--------------------------------------------------
Unit Size: 8 Byte
--------------------------------------------------
Latency: 2.824 ms
Effective Bandwitdh: 708.144 GB/s
Percentage of Peak Bandwitdh: 75.649%
**************************************************
Custom Device Memcpy 8-Byte Copy Per Thread
**************************************************
==================================================
Tensor Size: 262144 Units
==================================================
--------------------------------------------------
Unit Size: 1 Byte
--------------------------------------------------
Latency: 0.002 ms
Effective Bandwitdh: 238.792 GB/s
Percentage of Peak Bandwitdh: 25.509%
--------------------------------------------------
Unit Size: 2 Byte
--------------------------------------------------
Latency: 0.002 ms
Effective Bandwitdh: 434.723 GB/s
Percentage of Peak Bandwitdh: 46.440%
--------------------------------------------------
Unit Size: 4 Byte
--------------------------------------------------
Latency: 0.003 ms
Effective Bandwitdh: 681.196 GB/s
Percentage of Peak Bandwitdh: 72.770%
--------------------------------------------------
Unit Size: 8 Byte
--------------------------------------------------
Latency: 0.004 ms
Effective Bandwitdh: 1030.999 GB/s
Percentage of Peak Bandwitdh: 110.138%
==================================================
Tensor Size: 2097152 Units
==================================================
--------------------------------------------------
Unit Size: 1 Byte
--------------------------------------------------
Latency: 0.004 ms
Effective Bandwitdh: 978.128 GB/s
Percentage of Peak Bandwitdh: 104.490%
--------------------------------------------------
Unit Size: 2 Byte
--------------------------------------------------
Latency: 0.012 ms
Effective Bandwitdh: 677.416 GB/s
Percentage of Peak Bandwitdh: 72.366%
--------------------------------------------------
Unit Size: 4 Byte
--------------------------------------------------
Latency: 0.022 ms
Effective Bandwitdh: 696.748 GB/s
Percentage of Peak Bandwitdh: 74.431%
--------------------------------------------------
Unit Size: 8 Byte
--------------------------------------------------
Latency: 0.042 ms
Effective Bandwitdh: 738.924 GB/s
Percentage of Peak Bandwitdh: 78.937%
==================================================
Tensor Size: 134217728 Units
==================================================
--------------------------------------------------
Unit Size: 1 Byte
--------------------------------------------------
Latency: 0.320 ms
Effective Bandwitdh: 781.750 GB/s
Percentage of Peak Bandwitdh: 83.512%
--------------------------------------------------
Unit Size: 2 Byte
--------------------------------------------------
Latency: 0.636 ms
Effective Bandwitdh: 786.536 GB/s
Percentage of Peak Bandwitdh: 84.023%
--------------------------------------------------
Unit Size: 4 Byte
--------------------------------------------------
Latency: 1.265 ms
Effective Bandwitdh: 790.547 GB/s
Percentage of Peak Bandwitdh: 84.451%
--------------------------------------------------
Unit Size: 8 Byte
--------------------------------------------------
Latency: 2.530 ms
Effective Bandwitdh: 790.419 GB/s
Percentage of Peak Bandwitdh: 84.438%
**************************************************
Custom Device Memcpy 16-Byte Copy Per Thread
**************************************************
==================================================
Tensor Size: 262144 Units
==================================================
--------------------------------------------------
Unit Size: 1 Byte
--------------------------------------------------
Latency: 0.002 ms
Effective Bandwitdh: 216.744 GB/s
Percentage of Peak Bandwitdh: 23.154%
--------------------------------------------------
Unit Size: 2 Byte
--------------------------------------------------
Latency: 0.002 ms
Effective Bandwitdh: 414.641 GB/s
Percentage of Peak Bandwitdh: 44.295%
--------------------------------------------------
Unit Size: 4 Byte
--------------------------------------------------
Latency: 0.002 ms
Effective Bandwitdh: 829.282 GB/s
Percentage of Peak Bandwitdh: 88.589%
--------------------------------------------------
Unit Size: 8 Byte
--------------------------------------------------
Latency: 0.003 ms
Effective Bandwitdh: 1192.093 GB/s
Percentage of Peak Bandwitdh: 127.347%
==================================================
Tensor Size: 2097152 Units
==================================================
--------------------------------------------------
Unit Size: 1 Byte
--------------------------------------------------
Latency: 0.003 ms
Effective Bandwitdh: 1128.192 GB/s
Percentage of Peak Bandwitdh: 120.521%
--------------------------------------------------
Unit Size: 2 Byte
--------------------------------------------------
Latency: 0.010 ms
Effective Bandwitdh: 755.386 GB/s
Percentage of Peak Bandwitdh: 80.695%
--------------------------------------------------
Unit Size: 4 Byte
--------------------------------------------------
Latency: 0.023 ms
Effective Bandwitdh: 687.333 GB/s
Percentage of Peak Bandwitdh: 73.425%
--------------------------------------------------
Unit Size: 8 Byte
--------------------------------------------------
Latency: 0.043 ms
Effective Bandwitdh: 728.343 GB/s
Percentage of Peak Bandwitdh: 77.806%
==================================================
Tensor Size: 134217728 Units
==================================================
--------------------------------------------------
Unit Size: 1 Byte
--------------------------------------------------
Latency: 0.321 ms
Effective Bandwitdh: 779.006 GB/s
Percentage of Peak Bandwitdh: 83.219%
--------------------------------------------------
Unit Size: 2 Byte
--------------------------------------------------
Latency: 0.639 ms
Effective Bandwitdh: 782.639 GB/s
Percentage of Peak Bandwitdh: 83.607%
--------------------------------------------------
Unit Size: 4 Byte
--------------------------------------------------
Latency: 1.280 ms
Effective Bandwitdh: 781.520 GB/s
Percentage of Peak Bandwitdh: 83.487%
--------------------------------------------------
Unit Size: 8 Byte
--------------------------------------------------
Latency: 2.552 ms
Effective Bandwitdh: 783.602 GB/s
Percentage of Peak Bandwitdh: 83.710%
结论
从结果中我们可以看出：
-
我们拷贝的数据单元越多，有效内存带宽越高。 -
数据单元越大，有效内存带宽越高。 -
在大多数情况下，以8字节或16字节的向量化单元拷贝数据可以提高自定义设备内存拷贝的有效内存带宽，特别是当数据单元较小时。 -
使用共享内存来提高自定义设备内存拷贝的有效内存带宽的效果并不明显。
请注意，尽管我们可以在这个用例中直接使用CUDA官方的内存拷贝函数，但了解如何编写和改进自定义设备内存拷贝函数仍然很有价值，因为在更实际的CUDA应用中，要拷贝的数据可能在内存中不是连续的，我们可能需要从多个源拷贝数据到多个目标位置。
参考资料
-
CUDA Pro Tip: Increase Performance with Vectorized Memory Access(https://developer.nvidia.com/blog/cuda-pro-tip-increase-performance-with-vectorized-memory-access/)
（文：GiantPandaCV）
